AC Three-Phase Reluctance Motors Application
Product Overview
The AC Three-Phase Reluctance Motors Application, has been designed is to study the storage of the working principle and the main industrial operations fulfilled with three-phase reluctance motors.
Technical Specifications
ATENG 11135 — AC Three-Phase Reluctance Motors Application
- The application “ATENG 11135” includes the following elements:
- N-ALI01. Industrial Main Power Supply Module.
- Supply voltage: 400 VAC, 3PH + N.
ON / OFF removable key.
- Output voltage connections:
- Three-phase + Neutral: 400 VAC.
N-ALI01
- Single-phase: 230 VAC.
- Three-phase supply hose with IP44 3PN+E 32 A 400 V connecting plug.
- Differential magnetothermal 4 poles, 25 A, 30 mA AC 6 KA.
Emergency stop push-button.
- N-ARR12. Direct Starter Module.
- Nominal voltage: 400 VAC.
Three input terminals for power supply connection.
Six output terminals for motor connection.
- Maximum contacts current: 10 A.
- Two ON / OFF switches: N-ARR12
- 0: Open circuit.
- Y: Closed circuit.
- N-PUL48. Module with Three Dual Camera Push Buttons.
Two independent chambers.
- Nominal voltage: 24 VAC.
Three double chamber push-buttons (green and red).
- Contacts:
N-PUL48
Three normally open contacts (NO) for green switch.
Three normally close contacts (NC) for red switch.
- N-ARR11. Pole Reversing Switch Module.
- Nominal voltage: 400 VAC.
Three input terminals for power supply connection.
Six output terminals for motor connection.
- Maximum contacts current: 10 A.
- Two switches: N-ARR11
- Rotation Switch:
- 0: Open circuit.
- 1: Anti-clockwise.
- 2: Clockwise.
- Speed Switch:
- 0: Open circuit.
- 1: Speed 1.
- 2: Speed 2.
- N-LAM02. Auxiliary Lamps Module.
- Nominal voltage: 24 VAC.
Three lamps (red, yellow and green).
N-LAM02
3
Specificacions
- N-CON01. Three-Pole Contactor Module (24 VAC). (3 units)
- Nominal voltage for power contacts: 400 VAC.
- Nominal voltage for control contacts: 24 VAC.
- Nominal voltage for the control coil: 24 VAC.
- Contacts:
N-CON01
Three-phase normally open contact (NO) for power circuit.
Three normally open contacts (NO) for control circuit.
Two normally close contacts (NC) for control circuit.
- N-ALI03. AC Auxiliary Power Supply (24 Vac) Module.
- Voltage supply (single-phase): 230 VAC, 1PH + N.
- Output voltage:
- Single–Phase 24 VAC / 12 VAC.
- 24 VDC.
N-ALI03
- 0 – 24 VDC through potentiometer.
- N-REL30. Synchronization Relay Module.
- Nominal voltage for power contacts: 400 VAC.
- Nominal voltage for control contacts: 24 VAC.
- Nominal voltage for the control coil: 24 VAC.
- Contacts:
N-REL30
One three-phase normally open contact (NO) for power circuit.
- Three auxiliary contacts:
One instantaneous normally open contact (NO).
One time normally open contact (NO).
One time normally close contact (NC).
- EMT21. 3PH Reluctance Motor.
- Nominal power: 300 W.
- Nominal voltage: 3 x 400 VAC.
- Frequency: 50/60 Hz.
- Speed: 3000 rpm.
EMT21
- Nominal current: 1.4 A.
- Shaft height: 71 mm.
- N-TRANS03. Three-Phase Autotransformer 400/230 VAC, 1 kVA, Module.
Three-phase autotransformer.
- Nominal supply voltage: 400 VAC (3PH).
- Nominal output voltage: 3 x 230 VAC (3PH + N).
- Nominal power: 1 kVA. N-TRANS03
- Transformer connection: YY0.
Start/stop commutator for instantaneous connection/disconnection of the grid transformer.
- Fuses: 3 x 5 A.
- FLYW. Flywheel.
- Weight: 2 kg.
- Recommended maximum speed: 4000 rpm.
- Moment of inertia: 0.0025 kgm².
FLYW
4
Specificacions
