Gearbox Cut-Away, Heavy-Duty, with Reduction Gear Deluxe
Applications
This product is a cut-away representing a gearbox often found in heavy-duty vehicles (industrial and military). This gearbox with transfer case has two constant mesh gear pairs instead of one (normal constant mesh gear pair and constant mesh geared-down pair) which are located between the main shaft and transmission shaft.
Technical Specifications
Specifications
- 4-Speed gearbox
- 2 hand levers controls normal and reduced gears
- Normal gear ratios: 1st = 5.199, 2nd = 2.959, 3rd = 1.747, 4th = 1, R.M. = 5.243
- Reduced gear ratios: 1st = 7.013, 2nd = 3.991, 3rd = 2.357, 4th = 1.349, R.M. = 7.072
- Operated manually by hand crank
- Mounted on stand with wheels
Weight And Dimensions
Size: 80cm x 80cm x 140cm (L x W x H) Net Weight: 150 kg Gross Weight: 210 kg
