KNX for HVAC Control Training Application
Product Overview
The KNX for HVAC Control Training Application, is designed to facilitate the study and understanding of KNX-based Heating, Ventilation and Air Conditioning (HVAC) control systems.
Technical Specifications
ATENG 11099 — KNX for HVAC Control Training Application
- The ATENG 11096 Base Unit, “AEL-KNX-UB,” includes the following elements:
- N-KNX34. KNX/EIB USB Programming Interface Module.
- Power supply: KNX line, 21…30 VDC.
- Current consumption (max.): < 5 mA.
- USB connection: USB2.0 connector.
- N-KNX18. KNX/EIB Power Supply Module.
- Power supply: 230 VAC. N-KNX34
- Maximum load: 640 mA.
- Output voltage: 24 VDC.
- N-KNX4. KNX/EIB Binary Input Module.
- Nominal voltage: 230 VAC.
- Frequency: 50 Hz.
N-KNX18
- KNX bus voltage: 24 VDC.
- Mains inputs/outputs: 4 mm safety sockets.
- Bus inputs/outputs: 2 mm safety sockets.
- N-KNX5. KNX/EIB Binary Output Module. (2 units).
- Nominal voltage: 230 VAC.
- Frequency: 50 Hz. N-KNX4
- KNX bus voltage: 24 VDC.
- Mains inputs/outputs: 4 mm safety sockets.
- Bus inputs/outputs: 2 mm safety sockets.
- N-KNX30. Módulo de Panel Táctil KNX/EIB.
- Nominal voltage: 230 VAC.
N-KNX5
- Frequency: 50 Hz.
- KNX bus voltage: 24 VDC.
- Mains inputs/outputs: 4 mm safety sockets.
- Bus inputs/outputs: 2 mm safety sockets.
- N-KNX35. KNX/EIB Infrared Transmitter/Receiver Module.
- The IR remote is powered by two batteries of type alkaline (LR03/AAA; 1,5 V).
N-KNX30
- Normal functions:
Switching.
Switching and dimming.
Control of blinds.
- MED65. Digital Multimeter.
- Digital multimeter with 3 ½ digits, with 4 mm double connector termination cables to facilitate N-KNX35
interconnections.
- With this digital multimeter we will be able to measure:
Voltage.
Current.
Resistance.
Capacitors capacity.
MED65
Temperature.
- Required elements of the ATENG 11096 Base Unit, “AEl-KNX-UB” (at least one) (Not included):
ATENG 11098. KNX Lighting Control Training Application.
- N-KNX19. KNX/EIB Proximity Sensor Module.
- KNX bus voltage: 24 VDC.
- Bus inputs/outputs: 2 mm safety sockets.
- Working temperature: -5 °C to +45 °C.
N-KNX19
6
Specifications
- N-KNX20. KNX/EIB Push-Button Module.
Pushbuttons can be programmed for 1 or 2-button operation.
1 and 2 button operation for switching, dimming, blinds.
Change of values / scenes with up to 4 values.
Short/long push button and 2 object operation.
Group control with long/long button press.
- N-LAM32. One LED Lamp Module. (4 units).
- Lamp led 24 VDC.
- N-KNX8. KNX/EIB Dimmer Actuator Module
DALI dimmable driver.
- Power: 2 – 21 W.
N-LAM32
- Input voltage: 230 VAC.
- Output voltage: 9 – 42 V.
- N-DKG. DALI-KNX Gateway Module.
- Input voltage: 240 VAC.
- Frequency: 50/60 Hz.
- Communication port protocol: DALI. N-DKG
- Gateway: KNX/DALI.
- N-DAC. DALI Controller Module.
DALI input controller.
4 independent inputs for floating contacts.
For standard snap-action switch or circuit breaker connections.
N-DAC
- Power supply via DALI line: 24 VDC.
ATENG 11099. KNX for HVAC Control Training Application.
- N-KNX1. KNX/EIB Heating Actuator Module.
- Nominal voltage: 230 VAC.
- Frequency: 50 Hz.
- KNX bus voltage: 24 VDC.
- Mains inputs/outputs: 4 mm safety sockets.
N-KNX1
- Bus inputs/outputs: 2 mm safety sockets.
- N-KNX17. N-KNX17. KNX/EIB Movement Sensor Module.
Movement sensor for bus system KNX.
Max. transmission range frontally 7 m.
- Number of channels: 1.
N-KNX17
- N-KNX29. KNX/EIB Temperature Sensor Module.
- KNX bus voltage: 24 VDC.
- Bus inputs/outputs: 2 mm safety sockets.
- Range measurement: 0 – 40 °C (approx.).
- N-KNX33. KNX/EIB Window/Door Contact Module.
- KNX bus voltage: 24 VDC.
N-KNX29
- Bus inputs/outputs: 2 mm safety sockets.
